From: Andrés Ruiz
Date: 2008 Jun 10, 11:09 +0200
Dear Greg,
the answer to your SOS. Keep away from hungry mosquitoes! ;-)
Lines of Position
Fecha y hora UT1
09/06/2008
03:42:10
SITUACION ESTIMADA
Latitud: Be = 34.216667 º = 34º 13.0'
Longitud: Le = -119.316667 º = -119º 19.0'
ALMANAQUE NAUTICO
Cuerpo celeste: Estrella Vega
Polo de iluminacion del astro: Coordenadas Ecuatoriales
GHA = 34.114960 º = 34º 6.9'
Dec = 38.788671 º = 38º 47.3'
Correcciones altura:
SD = 0.000000 '
HP = 0.000000 '
CORRECION DE LA ALTURA
altura sextante [º]: Hs = 24.0917 = 24º 5.5'
correcion de indice [']: ie = 0.0000
altura del ojo sobre el nivel del mar [m]: heas = 6.0960
temperatura ambiente [ºC]: T = 10.0000
presion atmosferica [mb]: P = 1010.0000
en [º]:
altura observada por el sextante: Hos = 24.0917
depresion del horizonte: dip = 0.0724
altura aparente: Ha = 24.0192
correcion por refraccion: R = 0.0364
correcion por achatamiento: OB = 0.0000
Paralaje horizontal: HP = 0.0000
correcion por paralaje: PA = 0.0000
semidiametro: SD = 0.0000
Augmentation of SD = 0.0000
altura observada corregida: Ho = 23.9829 = 23º 59.0'
DETERMINANTE DE LA RECTA DE ALTURA
Angulo Horario Local: LHA = 274.798294 º = 274º 47.9'
Coordenadas Horizontales: Hc, Z
Altura Calculada: Hc = 23.9653 º = 23º 57.9'
Azimut: Z = 58.2 º
p = Ho-Hc = 0.017601 º = 1.056054 '
Fecha y hora UT1
09/06/2008
03:43:38
SITUACION ESTIMADA
Latitud: Be = 34.216667 º = 34º 13.0'
Longitud: Le = -119.316667 º = -119º 19.0'
ALMANAQUE NAUTICO
Cuerpo celeste: Estrella Spica
Polo de iluminacion del astro: Coordenadas Ecuatoriales
GHA = 112.381951 º = 112º 22.9'
Dec = -11.208231 º = -11º 12.5'
Correcciones altura:
SD = 0.000000 '
HP = 0.000000 '
CORRECION DE LA ALTURA
altura sextante [º]: Hs = 44.1767 = 44º 10.6'
correcion de indice [']: ie = 0.0000
altura del ojo sobre el nivel del mar [m]: heas = 6.0960
temperatura ambiente [ºC]: T = 10.0000
presion atmosferica [mb]: P = 1010.0000
en [º]:
altura observada por el sextante: Hos = 44.1767
depresion del horizonte: dip = 0.0724
altura aparente: Ha = 44.1042
correcion por refraccion: R = 0.0167
correcion por achatamiento: OB = 0.0000
Paralaje horizontal: HP = 0.0000
correcion por paralaje: PA = 0.0000
semidiametro: SD = 0.0000
Augmentation of SD = 0.0000
altura observada corregida: Ho = 44.0875 = 44º 5.3'
DETERMINANTE DE LA RECTA DE ALTURA
Angulo Horario Local: LHA = 353.065285 º = 353º 3.9'
Coordenadas Horizontales: Hc, Z
Altura Calculada: Hc = 44.0997 º = 44º 6.0'
Azimut: Z = 170.5 º
p = Ho-Hc = -0.012212 º = -0.732709 '
Fecha y hora UT1
09/06/2008
04:00:00
SITUACION ESTIMADA
Latitud: Be = 34.216667 º = 34º 13.0'
Longitud: Le = -119.316667 º = -119º 19.0'
ALMANAQUE NAUTICO
Cuerpo celeste: Estrella Pollux
Polo de iluminacion del astro: Coordenadas Ecuatoriales
GHA = 201.443544 º = 201º 26.6'
Dec = 28.007559 º = 28º 0.5'
Correcciones altura:
SD = 0.000000 '
HP = 0.000000 '
CORRECION DE LA ALTURA
altura sextante [º]: Hs = 21.2583 = 21º 15.5'
correcion de indice [']: ie = 0.0000
altura del ojo sobre el nivel del mar [m]: heas = 6.0960
temperatura ambiente [ºC]: T = 10.0000
presion atmosferica [mb]: P = 1010.0000
en [º]:
altura observada por el sextante: Hos = 21.2583
depresion del horizonte: dip = 0.0724
altura aparente: Ha = 21.1859
correcion por refraccion: R = 0.0418
correcion por achatamiento: OB = 0.0000
Paralaje horizontal: HP = 0.0000
correcion por paralaje: PA = 0.0000
semidiametro: SD = 0.0000
Augmentation of SD = 0.0000
altura observada corregida: Ho = 21.1441 = 21º 8.6'
DETERMINANTE DE LA RECTA DE ALTURA
Angulo Horario Local: LHA = 82.126877 º = 82º 7.6'
Coordenadas Horizontales: Hc, Z
Altura Calculada: Hc = 21.3501 º = 21º 21.0'
Azimut: Z = 290.1 º
p = Ho-Hc = -0.205998 º = -12.359890 '
Fix
Fix(34.183953781954251, -119.164604209542958) ( 34º 11.0' -119º 9.9') LopLSSR
Error : DO [deg] = 7.7957 nm
Andrés
De:
NavList@fer3.com [mailto:NavList@fer3.com] En nombre de Greg R.
Enviado el: martes, 10 de junio de
2008 1:10
Para: NavList
Asunto: [NavList 5388] 3-Star Fix
- "Canned Survival Problem"
last DR position (34° 13' N / 119° 19' W)
Soon after the sun faded in the western sky, the following sights were taken:
20:42:10 Vega 24° 05.5'
20:43:38 Spica 44° 10.6'
21:00:50 Pollux 21° 15.5'
Height of the eye is estimated to be 20' above the water, index error = 0.0', ZD = +7. Assume standard atmospheric conditions (the barometer and thermometer were also lost at sea).
--
GregR
--~--~---------~--~----~------------~-------~--~----~
